Outdoor Event Applications
The Steel Crank Up Light Stand is suitable for a variety of temporary event-production applications.
Outdoor Concerts
The adjustable height can be used to position compatible lighting or production equipment above the event area.
Event Lighting
The stand can support suitable lighting equipment where an elevated position is required.
Festival Production
Its crank-up design provides a reusable support solution for temporary event environments.
Stage Production
The stand can be incorporated into stage and entertainment production layouts.
Rental Companies
The reusable crank-up structure is suitable for event equipment rental operations.
Touring Productions
The supplied packing size of 2000 × 480 × 480mm provides a defined reference for transportation planning.
Packing & Transportation
According to the supplied product information:
Packing Information | Specification |
|---|
Packing Size | 2000 × 480 × 480mm |
Net Weight | 100kg |
The relatively compact packed dimensions compared with the maximum 7m operating height make the stand more practical for transportation between event venues.
Advantages for Professional Event Production
Wide Height Adjustment
1.8–7m height adjustment provides flexibility for different event layouts.
High Load Rating
The stated 250kg load capacity supports a range of professional event equipment applications.
Heavy-Duty Steel Structure
The 2.5mm material thickness and telescopic square-tube construction provide a robust mechanical structure.
1.8m Base
The stated 1.8m base length provides a substantial support footprint.
Transportable Configuration
The packed size is 2000 × 480 × 480mm, suitable for professional event logistics.
Product Dimensions at a Glance
Item | Dimension |
|---|
Minimum Lifting Height | 1.8m |
Maximum Lifting Height | 7m |
Base Length | 1.8m |
Top Bar Length | 0.5m |
Square Tube | 120 / 100 / 80 / 60 / 40mm |
Material Thickness | 2.5mm |
Packing Length | 2m |
Packing Width | 480mm |
Packing Height | 480mm |
Safety Considerations for Outdoor Use
Because the stand can reach 7m, outdoor environmental conditions should be considered carefully.
Before operation, users should verify:
The stand is positioned on a suitable surface.
The base and feet are properly installed.
The equipment is securely attached.
The total load remains within the stated capacity.
The stand is not exposed to unsuitable wind conditions.
The lifting mechanism operates correctly.
The structure is inspected before each use.
The supplied product page does not specify a maximum wind speed, ballast requirement, or outdoor wind-rating table. These values should therefore be confirmed with the manufacturer for the actual installation.
