LED PAR Light Connection Bracket for Stage & Event Lighting Fixture Mounting

• Designed for Stage Lighting Applications
  Suitable for compatible LED PAR light and stage lighting fixture connection applications.

• Four Configuration Options
  C001, C002, C003 and C004 provide different hole spacing and height combinations.

• 30mm Width
  All four supplied configurations have a stated product width of 30mm.

• Multiple Hole Spacing Options
  Available hole spacing includes 105mm, 115mm and 150mm, providing different mounting options for compatible fixtures.

• Compact Profile
  Product height ranges from 35mm to 42mm, depending on the selected configuration.

• Lightweight Construction
  Product weight ranges from approximately 0.17kg to 0.23kg, depending on the model.

• Suitable for Event & Production Use
  Can be considered for stage lighting, event production, exhibition and entertainment lighting setups where the dimensions match the fixture mounting arrangement.

Model Selection

C001

• Hole spacing: 105mm

• Width: 30mm

• Product height: 35mm

• Product weight: 0.17kg

C001 is the lightest of the four supplied configurations and can be selected where the 105mm hole spacing and 35mm height match the fixture mounting arrangement.

C002

• Hole spacing: 115mm

• Width: 30mm

• Product height: 35mm

• Product weight: 0.175kg

C002 provides a 115mm hole spacing while maintaining the same 30mm width and 35mm height as C001.

C003

• Hole spacing: 150mm

• Width: 30mm

• Product height: 35mm

• Product weight: 0.195kg

C003 provides the largest stated hole spacing at 150mm, making it suitable for compatible fixtures requiring this mounting dimension.

C004

• Hole spacing: 105mm

• Width: 30mm

• Product height: 42mm

• Product weight: 0.23kg

C004 uses the same 105mm hole spacing as C001 but has a greater product height of 42mm.

The DragonStage Connection Bracket can be considered for compatible:

• LED PAR light mounting

• Stage lighting fixtures

• Concert lighting setups

• DJ and entertainment lighting

• Festival lighting

• Event production systems

• Exhibition booth lighting

• Performance venues

• Temporary stage installations

• Lighting fixture connection and mounting

The actual suitability depends on the fixture dimensions, hole pattern and complete mounting arrangement.

Compatibility & Installation Notes

Before ordering, carefully check the mounting dimensions of the intended fixture.

1. Check the hole spacing
   Select C001, C002, C003 or C004 according to the required mounting hole spacing.

2. Check the bracket height
   Confirm whether the 35mm or 42mm height is suitable for the intended installation.

3. Check the available mounting space
   All four versions have a stated 30mm width.

4. Check the fixture connection
   Confirm that the LED PAR light or other fixture has a compatible mounting hole arrangement and fastening method.

5. Check the complete mounting system
   The bracket should be used only where the fixture, fasteners, support structure and connection arrangement are suitable for the intended application.

6. Inspect before installation
   Check the bracket and associated fastening components for visible damage, deformation or excessive wear before use.

Safety Considerations

This product is described as a connection bracket. No maximum safe working load has been supplied for the four configurations.

Therefore, the product dimensions and weight should not be interpreted as load-capacity specifications.

For elevated or suspended stage lighting applications, confirm the load capacity of the complete mounting system, including the fixture, bracket, fasteners and supporting structure, before installation.

1. What is the LED PAR Light Connection Bracket used for?

It is designed as a connection accessory for compatible LED PAR lights and stage lighting fixtures.

2. How many models are available?

Four configurations are specified: C001, C002, C003 and C004.

3. What is the width of the brackets?

All four supplied models have a stated width of 30mm.

4. What hole spacing options are available?

The supplied configurations provide 105mm, 115mm and 150mm hole spacing.

5. Which model has 150mm hole spacing?

C003 has a hole spacing of 150mm.

6. What is the difference between C001 and C004?

Both have 105mm hole spacing and 30mm width. C001 has a 35mm height and 0.17kg weight, while C004 has a 42mm height and 0.23kg weight.

7. Which model is the lightest?

C001 is the lightest supplied configuration at approximately 0.17kg.

8. Is the material specified?

The supplied product information does not specify the material, so no material grade is stated here.

9. Does the product have a specified load capacity?

No. A maximum load or SWL was not provided for these connection brackets.

10. How do I select the correct model?

Compare the required hole spacing, bracket height and available mounting space with the four supplied configurations before ordering.
