300kg Aluminium Stage Clamp for Festival Lighting and Concert Rigging

• Aluminium Alloy Construction
  Made from aluminium alloy for compatible stage lighting and event equipment mounting applications.

• 300kg Maximum Safe Load-Bearing Capacity
  The supplied product specification states a maximum safe load-bearing capacity of 300kg. Confirm the applicable rating definition and test conditions before relying on this figure for a specific installation.

• 40–52mm Round Pipe Compatibility
  Designed for compatible round pipes with an outer diameter between 40mm and 52mm.

• 50mm Product Width
  The specified width is 50mm, providing a reference dimension for mounting clearance and compatibility checks.

• 63mm Product Height
  The specified height is 63mm. Confirm that the dimensions suit the intended mounting arrangement.

• Lightweight 0.48kg Design
  The stated product weight is approximately 0.48kg, useful for equipment handling and transport planning.

• Two Finish Options
  Available in polished natural aluminium or oxidized black.

• Custom Colours and Surface Treatments
  Other colours and surface treatments can be requested, subject to supplier confirmation.

• Suitable for Compatible Event Lighting Setups
  Can be considered for festival lighting, concert production and professional event rigging where the pipe dimensions, equipment interface and complete support system are suitable.

The 300kg Aluminium Stage Clamp can be considered for compatible mounting arrangements in:

• Festival stage lighting installations

• Concert and live music production

• Professional event lighting setups

• Theatre and performance venues

• Temporary event structures

• Entertainment and production environments

• Lighting equipment replacement and maintenance

These are potential applications rather than confirmation of compatibility with every fixture or support structure. Check the mounting interface and installation requirements before use.

For supporting event infrastructure, explore Truss & Rigging and Truss & Rigging Accessories.

1. What is the 300kg Aluminium Stage Clamp used for?

It is a mounting accessory intended for compatible stage lighting and event equipment installations using suitable round pipe structures.

2. What pipe diameter does this clamp fit?

The supplied specifications state compatibility with round pipes having an outer diameter of 40–52mm.

3. What is the maximum safe load-bearing capacity?

The supplied product specification states 300kg. Confirm the rating definition and applicable test conditions before relying on this value for a specific installation.

4. What material is the clamp made from?

The product is specified as being made from aluminium alloy. The exact alloy grade has not been provided.

5. What are the product dimensions and weight?

The specified product width is 50mm, the height is 63mm, and the approximate product weight is 0.48kg.

6. Which finishes are available?

The specified options are polished natural aluminium and oxidized black. Other colours and surface treatments can be requested, subject to customization confirmation.

7. Can this clamp be used with any stage lighting fixture?

No. Compatibility depends on the supporting pipe diameter, the fixture mounting interface and the complete installation arrangement. Verify these details before ordering.

8. Does the 300kg rating guarantee that a complete suspended installation is safe?

No. The stated clamp capacity alone does not establish the allowable load of the complete installation. The supporting structure, fixture, fasteners, connections and installation conditions must also be assessed.

9. Are mounting hardware and certifications included?

The supplied product information does not confirm package contents or certification status. Contact the supplier to verify these details if required for your project.
